HT/1003MKII (aka The Hammer) Insane Performance at its Size and Price

Buy an HT/1003 MKII if you either don’t have the space or don’t require the extra output of our larger models. It’s that simple. More compact, just as beautiful, it delivers identical build quality to its siblings. It’s style makes it an ideal partner in HT/3D REL theatre setups with Serie T/x.

All-new 300W Class D amplifier offers greater headroom and powers a new CarbonGlas™ 10” (250mm) driver. This combination delivers devastating output, playing TWICE as loud as the original. At this price, this performance is unheard of. The icing on the cake is that, like all the new HT’s, it responds beautifully when playing music, and HT-Air delivers state of the art (optional) wireless.

When Your Heart Says HT/1205

BUT YOUR WALLET OR YOUR ROOM SAYS NO

Perhaps the most dramatic update in the entire HT range is delivered by the remarkable HT/1003 MKII. In theatre, nothing impresses like raw output, even if you don’t use all of it. HT/1003 MKII’s increase in usable headroom confers an ease to the sound that lesser designs can’t compete with. Here, we realize a full 10 dB higher output (that’s twice as loud) over its forbear. As with its larger brothers, HT/1003 MKII receives the full suite of MKII upgrades. First, a higher secondary filter allows energy to extend further up the sonic spectrum means explosions are more savage than ever. Next, an all-analogue PerfectFilter™ lifts and extends the deepest bass. Additionally, an analogue subsonic filter filters out the signals that can lead to damage below 20Hz. All this is packaged in the same sexy, serious look that blends perfectly with our Serie T/x and S for use in HT-3D systems. Also, improvements to driver, amplifier, and filters means this latest version is now a seriously musical sub.

Designer Clothing

The sexy new cabinetry is bespoke, with new textures, proportions, and finishing touches previously unseen in the category. Lower, sleeker cabinetry borrows proportions from our new Reference models. Faster, deeper bass presentation with hand-polished piano black lacquer top panel.

Drive Like You Mean It

10” CarbonGlas™ driver with glass fibre primary cones and carbon fibre center caps. Upgraded suspension and larger magnets for controlled, high-output performance. Perfect for both music and theatre setups.

Amplified Excellence

300W RMS continuous amp with upgraded power supplies and thicker boards. Perfectly balanced for theatre and musical applications, delivering robust, awe-inspiring sound.

PerfectFilters™

Ultra-fast analogue crossovers, elevation filters, and all-analogue subsonic filter down to 12 Hz. Delivers power to the driver’s limit without distortion for explosive realism in music and film.

Wired For Sound: HT-Air

Optional HT-Air™ transmitter/receiver delivers 5.8GHz wireless signal up to 60 feet with no digital compression. Perfect for .1/LFE signals using RCA connectors. Un-wired, yet ultra-fast and reliable.

Visual Highlights

Sleek, bespoke cabinetry with hand-polished piano black lacquer and discreet REL logo. Looks expensive, restrained, and perfect for immersive HT/3D™ setups.
Read More
Read Less

TYPE

Enclosure Type

Closed box, front-firing driver

DRIVER

Active Driver Size & Material
  • 10 in. (250mm) long-throw
  • CarbonGlas™ cone structure
  • Inverted carbon fibre dust cap
  • Steel chassis
Passive Radiator Size & Material

N/A

Low Frequency Extension

−6dB at 24 Hz

CONNECTIVITY

Input Connectors

Dual purpose Low Level stereo RCA or LFE RCA

Output Connectors

Daisy Chain Low Level stereo RCA or LFE RCA

AMPLIFICATION

Power Output

300 watts (RMS)

Amplifier Type

NextGen5 Class D

WIRELESS CAPABILITY

Wireless Option
  • HT Air Wireless (Optional)
  • Zero Compression Single Large Scale Integrated Chip

FILTER

Dual Parametric Filter

N/A

PROTECTION SYSTEM

Protection Features
  • Fully Electronic Set Safe: Yes
  • D.C. Fault: Yes
  • Output Short: Yes

POWER

Mains Input Voltage

220–240 volts

Fuses

6.3 Amp semi delay (230V)

DIMENSIONS AND WEIGHT

Dimensions (W × H × D)

362mm × 343mm × 387mm

Net Weight

15.5kg

Shipping Weight

18.6kg

FINISH

Cabinet Finish
  • Line Grained Black Composite
  • Horizontally Oriented Line Grained Black Composite Cabinet
  • 15mm Top Plate
  • Finished in 5 coats of Hand-Rubbed High Gloss Black Lacquer

SUPPLIED ACCESSORIES

Mains Lead

Yes

Neutrik Speakon Interconnect

No

User Manual

Yes
