B&W ASW610
Black - $1,299.00
Description

Fill the room with bass, not speakers

ASW610 is compact, making it a subwoofer you can squeeze in anywhere. Or maybe use two for more bass control?

Sealed tight

ASW610's sealed enclosure keeps the bass good and tight (and exciting!).
Read More
Read Less

Size & Weight

  • Net weight:

12.5 kg

  • Dimensions:
    Height:

310 mm (no feet/spikes), 322 mm (with feet), 338 mm (with spikes)


Width:

310 mm


Depth:

347 mm (no grilles), 375 mm (with grilles & controls)

Technical Details

  • Drive units:

250 mm (10 in) Paper / Aramid fibre cone, long-throw

  • Frequency response:

±3 dB, 27 Hz – 40/140 Hz adjustable (EQ at A)

  • Description:

Active closed-box subwoofer system

  • Frequency range:

–6 dB at 20 Hz and 25/140 Hz adjustable (EQ at A)

  • Inputs:

Line in (RCA Phono)
Speaker in (Binding post)
12 V trigger (3.5 mm jack)

  • Low-pass filter:

Active 4th-order, variable cut-off frequency


Amplifier power output:

200 W

  • Power consumption:

40 W (0.5 W standby)

  • Input impedance:

33 kΩ

  • Signal / Noise:

>90 dB

  • Bass extension:

–6 dB at 20 Hz (Position A)
–6 dB at 25 Hz (Position B)
–6 dB at 30 Hz (Position C)

  • Technical features:
    Input level (line in)
    Input level (speaker in)
    Low-pass filter frequency (line in only)
    Low-pass filter bypass
    Bass extension
    Bass roll-off alignment
    Auto sense on/standby
    Phase switch

Finishes

  • Cabinet finishes:

Black, White

  • Grille finishes:

Black, Grey
