Super easy setup
WiiM Mini will pop up automatically in the WiiM Home app. Follow the in-app guide
and start streaming music in less than 2 minutes.
Stream Hi-Res audio up to 192 kHz/24 bit.
WiiM Mini supports up to 192kHz, 24-bit audio output. That's the same as an artist's recording in the studio. The integrated TI stereo DAC provides high-quality analog audio output with 106-dB SNR, dynamic range, and -92dB THD+N performance.
All your content in one app
We support many popular music streaming services in our WiiM Home app with more to come. Or connect to your NAS or local files to stream your favorite music.
Key Features
- Supports Hi-Res audio up to 192 kHz/24 bit
- Wireless Multi-room audio - group multiple units for a connected system
- Spotify Connect & Tidal Connect
- Airplay 2
- Dual band WiFi & Bluetooth 5.0
- Super easy setup with the WiiM Home app
- Works with Siri & Alexa smart devices
- Group with Homepod & Amazon Echo devices
- Aux input for connecting an analogue source
- Analog and SPDIF audio output
- USB-C to USB-A Cable included
- Powered by USB-C port - wall adapter not included, requires standard 5V 1A USB-A charger (most iPhone / android chargers)
High-Res Audio
The WiiM Mini supports playback of Hi-Res lossless audio content from services such as TIDAL, Qobuz, Amazon Music, Deezer and more. It supports up to 192kHz, 24-bit audio output via the optical line out.
The integrated TI stereo DAC provides high quality analogue audio output with 106-dB SNR, and -92dB THD+N performance, outstanding in all audio categories.
Gapless Playback
Precise gapless playback can be very important to your listening experience. With precise gapless playback, the playback timing is guaranteed to be identical to the source. The WiiM Mini will not introduce gaps or overlaps (crossfading) between successive "continuous" tracks such as live recordings or concept albums.
Multiroom and stereo pairing
The WiiM Mini features perfect audio synchronization and seamless device control via the companion App allowing you to group multiple devices together to create a complete connected system throughout your home. Through careful hardware and software optimisation, the WiiM Mini can achieve less than 150uS (0.00015s!) synchronisation accuracy among speakers as long as the speakers are on the same wireless network. Thus, your speaker system can be located wherever your Wi-Fi network covers.
In addition, you can join two speakers each connected to a WiiM Mini as a stereo pair for a wider, more immersive sound stage.
Auto calibration of audio delay
Any connected receiver or speaker may introduce audio path latency due to the different hardware, software or DSP processing involve in that device. To maintain the synchronisation of each system, the WiiM mini can measure the audio path delay automatically. By leveraging the on-device microphone and proprietary algorithm, the entire audio path latency is measured automatically when it's connected with a receiver or speaker. The latency value will be adjusted to maintain the perfect audio synchronisation in wireless multi-room or multi-channel playback.
Adaptive EQ
When the WiiM Mini's Adaptive EQ is enabled, the music genre information and other tags included in the audio content's meta data are used to adjust the EQ in real time - either bringing rich audio to capture every music detail or making human voices clearer in podcasts.
All contents in one App
The WiiM Home app supports many top music streaming services including: Spotify, iHeartRadio, Tidal, Amazon Prime Music, Napster, Deezer, & more to come.
It's more convenient than ever to have your music and device control in one place. With the WiiM Home app, you can easily browse all your favourite music services without jumping between multiple apps. Enjoy your favourite audio from all services in one single App. Additionally, you can control the device EQ, setup a music alarm, and create a personalised routine via the WiiM home app.
Music Alarm
Wake up to, or sleep with your favourite music, radio station, or podcast online. The WiiM Home app slowly adjusts the volume during a music alarm or sleep timer for better a sleep and rise.
Specifications:
Dimensions: 69 x 69 x 24mm
Weight: 40g
Audio Codec: MP3, AAC, ALAC, APE, FLAC, WAV, WMA, OGG
Wi-Fi: Dual band Wi-Fi supports 802.11 a/b/g/n/ac 2.4 GHz and 5 GHz network
Bluetooth: Bluetooth 5.0, SBC and AAC codec, BT receiver and transmitter (with SW update)
Line in: 1Vrms
Line out:
Line in to Line out：
- Power Output=2Vrms
- THD+N Ratio=0.009%
- SNR=102dB
- Crosstalk=-106dB
- Dynamic Range=96dB
BT in to Line out:
- Power Output=2Vrms
- THD+N Ratio=0.009%
- SNR=102dB
- Crosstalk=-106dB
- Dynamic Range=96dB
SPDIF out:
Line in to SPDIF out：
- Power Output=-3dBFS
- THD+N Ratio=0.005%
- SNR=102dB
- Crosstalk=-103dB
- Dynamic Range=97dB
BT in to SPDIF out：
- Power Output=0dBFS
- THD+N Ratio=0.005%
- SNR=297dB
- Crosstalk=-364dB
- Dynamic Range=213dB
Power Supply: USB-C port, 5V, 1A (wall adaptor not included)
LED: Three colour status LED - Red, Green and White
Buttons: Capacitive touch - Play/Pause, Volume+, Volume-
What's in the box?
- Wiim Mini
- USB-C to USB-A cable for power (wall adapter not included, USB-C to USB-A cable included, requires 5V, 1A charger - most iPhone / Android chargers)
- Optical SPDIF cable
- 3.5mm to 3.5mm analogue audio cable
- 3.5mm to 2RCA analogue audio cable
- User manual
