Exposure XM9 Mono Power Amplifier
Click to zoom in

Exposure XM9 Mono Power Amplifier

$4,999.00
$4,999.00

Features

  • Large 200VA custom-made toroidal power transformer
  • High quality all aluminium casework and extruded front panel
  • High quality resistors & capacitors used in the signal path
  • Cascode circuitry utilised for improved power supply immunity
  • Toshiba bipolar output transistors for dynamics and performance
  • 80 watts per channel into 8 ohms
  • Unbalanced & balanced input selectable by internal link
  • DC coupled throughout
  • Electronic, non invasive current overload protection
  • Bi-wire speaker outputs using high quality shrouded sockets
  • Three year guarantee
  • Available in black or titanium
Read More
Read Less
Power Output (1 kHz)

80 watts per channel into 8 ohms

Total Harmonic Distortion

@ 1 kHz, rated power: 0.005%

Frequency Response

20 Hz – 20 kHz ±0.5 dB

Input Sensitivity, Unbalanced (ref 1 kHz rated output)

1.6 V RMS

Gain

Unbalanced input ×16, 24 dB @ 1 kHz

Input Impedance, Unbalanced

77K ohms

Signal to Noise, Unbalanced (ref 1 kHz rated output)

95 dB

Mains Supply

110/120V or 220/240V @ 50/60 Hz (factory set)

Power Consumption

200 W

Dimensions (W × H × D)

218 mm × 89 mm × 363 mm (inc knob)

Net Weight (unpacked)

5 kg

Gross Weight (packed)

6 kg
